-  Support IV, NIV- Suitable For Neonatal, Pediatric And Adult
 Color TFT LCD Display 15.6"
 Fully Electronic Control
 Ventilation Type: Blower
 More Than 10 Types Ventilation Modes Can Meet Your Almost All   Requirement
 Ventilation Modes: A/C-VCV, A/C-PCV, A/C-PRVC, SIMV-VC, SIMV-PC,   SIMV-PRVC, BIPAP, APRV, CPAP/PSV, CPAP-VG, NIV, IV.
 Support High Pressure And Low Pressure Gas Source
 Tidal Volume: - 5 To 2000mL

DESCRIPTION
Set up The screen of the ventilator is suitable for controlling certain functions of the device,entering setting parameters and graphically displaying the measured values,as well as for handling alarms.
Features
Support IV, NIV.
Suitable for neonatal, pediatric and adult.
More than 10 types ventilation modes can meet your almost all requirement.
Support high pressure and low pressure gas source.
All components of the gas pathway to the patient are PVC-free.
The body is resistant to electromagnetic interference (electroanngnetic compatibility and electrical safety testing)
The device operates in the range of 5°C to 40 °C up to 95% humidity.

Monitoring Real-time waveforms: Paw, Flow, Volume, EtCO2, SPO2

Optional : CO2, SPO2 (related parameters)
Loops : P-V, V-Flow, Flow- P Trends: 1s, 5s,1 min,10min, 30min, 60min Display method : Numerical and graphical trends

Control
Tidal volume: - 5 to 2000mL
Rate: - 1 to 10Obpm
PEEP/CPAP: - Oto 50 cmH2O
FiO2: - 21 to 100%
l:E ratio: - 1:10 to 4:1
Inspiratory time (Tl): - 0.2 to 12s
Apnea absence: - 10 to 30s
Flow trigger Pressure trigger: - 0.2 to 15 l/min -0.5 to-20cmH2O
Pressure control: - 5 to 90 cmH2O
Pressure support: - 0 to 80 cmH2O, added to PEEP/CPAP
Pressure ramp: - 0 to 2s
Expiratory trigger sensitivity (ETS): OFF, 5 to 90 % of inspiratory
peak flow Peak flow Spontaneous: > 200 L/min
Mechanical safety pressure valve opening range: 80 to 125 cmH2O

Electrical and gas supplies
Input voltage: 110 to 240V ~ ±10 %, 50 / 60 Hz AC or 24 VDC±10 % Power consumption: - 50 W
typical Protection class: - Class I
